Capacity Range upto 1500 kVA 3 Ph
| Input Voltage Range | 300-460V / 340-480V / 360-460V AC 3 Ph |
| Output | 415/200V 3ph as per requirement |
| Insulation | Class H |
| Speed of Correction | 60/30/25 V per Sec. with AC motor 105 V/ Sec. with DC motor |
| Response Time | 10 milliseconds |
| System Connections | Delta/Star |
| Ratios | 1:1 and 2:1 |
| Regulation | Better than 3.5% |
| Power Factor | 0.75 Lead to 0.75 Lag |
| Di-electric Strength | 3KV for 60 sec |
| Insulation Resistance | Better than 1000 Mega ohms |
| Coupling Capacitance | 0.01 PF for 100 Db |
| Leakage Current | Less than 20 Micro Amps |
| Common Mode Attenuation | 100 Db/120 Db |
| Construction Standards | As per IS 2026 Part 1 &|| |
| Type of Execution | Closed Type |
| Operating Temperature | 0°C to 45°C |
| Type of Cooling | Natural air/Forced air |
Most Suitable for
-
CNC Machines
-
Telecommunication Equipments
-
Bio Medical Equipments
-
Large Computer Installations
-
Printing Machinery
-
Scientific Equipments
-
Cell Phone Networks
-
Garment Equipments
-
Textile Machineries... and many more
-
Cell Phone Networks
-
Garment Equipments
-
Textile Machineries... and many more
-
Garment Equipments
-
Textile Machineries... and many more
Trouble Free Operation
-
Quick response time 10 milli sec (half a cycle)
-
Efficiency, Low losses, Low temperature rise and withstands in all climatic conditions
-
Provides perfectly stable output power even under sever conditions of voltage fluctuations
-
Zero wave - form distortion
-
Unaffected by load power factor
-
Ruggedized construction
-
Enclosure - IP32
-
Mounting - Floor Mounted / Free on Wheel
-
Servo Motor Drive - Rugged ac step synchronous motor
High reliability
-
Uses solid state control circuits
-
Synchronous motor drive
-
No warm - up time
-
No relays
-
Professional grade Ics and Components are used
-
Synchronous motor drive
-
No warm - up time
-
No relays
-
Professional grade Ics and Components are used
-
No relays
-
Professional grade Ics and Components are used
