Capacity Range upto 1500 kVA 3 Ph
| System Connections | Delta / Star |
| Input Voltage | 415V 3 Phase 50 Hz / 60 Hz |
| Output Voltage | 415V or 200V 3 Phase 50 Hz / 60Hz |
| Ratios | 1:1 and 2:1 |
| Regulation | Better than 3.5% |
| Power Factor | 0.75 Lead to 0.75 Lag |
| Di-electric Strength | 3KV for 60 sec |
| Insulation Resistance | Better than 1000Mega Ohms |
| Coupling Capacitance | 0.1 PF for 80 db |
| Leakage Current | Less than 20 Micro Amps |
| Common Mode Attenuation | 80 db / 100 db |
| Construction Standards | As per IS 2026 Part I & II, IS I 1171 |
| Type of Execution | Closed Type |
| Operating Temperature | 0 C to 45 C |
| Type of cooling | Natural Air / Forced air Oil cooled (optional) |
Programmable Parameters
| Input | Output | Rating Available |
|---|---|---|
| 415 V AC 3 Ph | 415 V AC 3 Ph | 3 KVA 3 ph and upto 1500 KVA 3 ph |
| 415 V AC 3 Ph | 220 V AC 3 Ph | 3 KVA 3 ph and upto 1500 KVA 3 ph |
| 230 V AC 1 Ph | 230 V AC 1 Ph | 1 KVA 1 Ph and upto 50 KVA 1 Ph |
| 230 V AC 1 Ph | 110 V AC 1 Ph | 1 KVA 1 Ph and upto 50 KVA 1 Ph |
-
Cell Phone Networks
-
Oil & Vanaspathi Plants
-
Scientific Equipments Large Computer Installations
-
Garment Equipments... and many more.
Most Suitable for
-
CNC Machines
-
Printing Machineries
-
Textile Machineries
-
Bio Medical Equipments
-
Cell Phone Networks
-
Oil & Vanaspathi Plants
-
Scientific Equipments Large Computer Installations
-
Garment Equipments... and many more.
-
Eliminates stresses that come from normal electrical transients.
-
Meet stringent clean power requirements of the sophisticated / sensitive equipments
-
Reduces the effects of power line problems like Noise, Spikes, Surges, Transients and Neutral to minimum levels
-
